Weld Neck Flanges (WNRF)

Weld Neck Flange is flanges that designed to be joined to a piping system by butt welding. This kind of flange include lots of specification.

Weld Neck Flange is expensive because of its long neck and cost of people for contact WN flange with pipeline or fitting but is preferred for high-stress applications. The necks, or hubs, transmits stresses to the pipeline.

The gradual transition of thickness from the base of the hub to the wall thickness at the butt weld provides important reinforcement of the Weld Neck Flange. The bore of Weld-Neck flange matches bore of the pipeline, reducing turbulence and erosion.

Weld Neck Flange is flanges that designed to be joined to a piping system by butt welding. This kind offlange include lots of specification, Weld neck Flange is expensive because of its long neck and cost of people for contact WN flange with pipeline or fitting but is preferred for high stress applications. The necks, or hubs, transmits stresses to the pipeline.

The gradual transition of thickness from the base of the hub to the wall thickness at the butt weld provides important reinforcement of the Weld Neck flange. The bore of Weld-Neck flange matches bore of the pipeline, reducing turbulen.

Material & Grades of Weld Neck Flanges (WNRF) :

Stainless Steel Weld Neck Flanges :

ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L

Duplex & Super Duplex Steel Weld Neck Flanges :

ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61

Carbon Steel Weld Neck Flanges :

ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706 Low Temperature Carbon Steel Weld Neck Flanges : ASTM A350, LF2, LF3

Alloy Steel Weld Neck Flanges :

ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91 Copper Alloy Steel Weld Neck Flanges : ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200

Nickel Alloy Weld Neck Flanges :

ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020)

ASME B16.5 Raised Faced Weld Neck Flanges Available Types

Note: Welding Neck bore is derived from the pipe schedule

ANSI B16.5 Weld Neck Flanges Application

ASME B16.5 Weld Neck Flanges are known to deliver exceptional performance and are generally developed for
meeting the demands. We oer a broad range of Flat Faced Weld Neck Flanges through a worldwide network of
stock-keeping branches. This Weld Neck Flange is used in various industries like :
 Stainless Steel Weld Neck Flanges uses in Oil and Gas Pipeline
 Weld Neck Raised Face Flanges uses in Chemical Industry
 Alloy Steel WNRF Flanges uses in Plumbing
 Flat Faced Weld Neck Flanges uses in Heating
 Weld Neck Pipe Flanges uses in Water Supply Systems
 ANSI B16.5 Weld Neck Forged Flanges uses in Power Plant
 Weld Neck Plate Flanges uses in Paper & Pulp Industry
 Weld Neck Flange uses in General Purpose Applications
 Steel Weld Neck Flanges uses in Fabrication Industry
 Weld Neck Flange uses in Food Processing Industry
 Weld Neck Flanges uses in Structural Pipe
