Stainless Steel ASTM Fittings, SS Buttweld Pipe Fittings, ANSI B16.9, ANSI B16.28,
MSS-SP-43, or MSS-SP-79 Stainless Steel 304 Buttweld Pipe Fitting, Manufacturer Of ASTM A403 WP304 Stainless
Steel Buttweld Fittings in MengCun, China.
Wrought Austenitic Stainless Steel 304 Pipe Fitting, Stockholder Of Stainless Steel WP304 Tee, ASME SA403M
Stainless Steel WP 304 Stub End Wholesaler, Best Price of 304 SS Pipe Cap Exporter, SS Grade WP304 Pipe Elbow,
Stainless Steel 304 Seamless Pipe Fittings Traders in China.
HGFF Group Co.,Ltd is one of the prominent Stainless Steel Pipe Fittings Manufacturers in China. Our offered SS Buttweld Elbow has good resistance to chloride stress – corrosion cracking, carburization, and excellent resistance to reducing or carburizing atmospheres. Our SS Buttweld Equal Tee widely used in most industrial applications like power plants, chemical, offshore, automobile and heavy engineering.
We are the largest stockholder of Stainless Steel Butt Weld Fittings includes ASTM A403 SS Pipe Elbow, SS Buttweld Tee, ASME B16.9 Stainless Steel Cross that are produced in a variety of specifications, designs, sizes and grades, with each fitting serving an industry’s need. our MSS SP 43 SS stub ends have resistance to atmospheric corrosion and serve general purposes like sealing pipe ends and preventing any contamination to the internal fluids. Also, We offer a wide range of stainless steel ASTM A403 stainless steel seamless pipe fittings such as SS buttweld Tee, SS End Pipe Cap, SS reducer at the cheapest price in China
| Specifications : | ASTM A403 / ASME SA403 |
| Dimensions : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size : | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Type : | Seamless / Welded / Fabricated |
| Bending Radius : | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Thickness : | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| ASTM A403 – ASME SA403 – | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 – | Factory-Made Wrought Buttwelding Fittings |
| MSS SP-43 – | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| BS3799 – | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| Origin & Mills: | Indian Origin, Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin, Russian Origin, Indian Mills, Japanese Mills, Korean Mills, European Mills, US Mills, Russian Mills, Ukraine Mills |
| All Fittings | 90°and 45° Ells and Tees | Reducers and Lap Joint Stub | Caps | 180° Returns | Angularity Tol | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Plane Size (NPS) | Outside(1)Diameter at Bevel | Inside(1)Diameter at End | Wall(2) Thickness | Centre-to- End Dimension A,B,C,M | Overall Length L | Overall Length E | Centre-to- Centre Dimension O | Back-to- Face Dimension K | Alignment at Ends U | Nominal Pipe SIze | Off Angle Q | Off Angle P |
| 1/2 TO 2-1/2 | +1/16 | ±1/32 | Not less than 87-1/2% of Normal Thickness | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 12 to 4 | 1/32 | 1/16 |
| -1/32 | 5 to 8 | 1/16 | 1/8 | |||||||||
| 3 TO 3-1/2 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 10 to 12 | 3/32 | 3/16 | |
| 4 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 14 to 16 | 3/32 | 1/4 | |
| 5 TO 8 | +1/32 | ±1/16 | ±1/16 | ±1/16 | ±1/4 | ±1/4 | ±1/4 | ±1/32 | 18 to 24 | 1/8 | 3/8 | |
| -1/16 | ||||||||||||
| 10 TO 18 | +1/16 | ±1/8 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | All dimensions are in inches | |||
| -1/8 | ||||||||||||
| 20 TO 24 | +1/4 | ±3/32 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | ||||
| -3/32 | ||||||||||||
Stainless Steel 304 Buttweld Pipe Fittings Application
ASTM A403 WP304 Pipe Fittings are known to deliver exceptional performance and are generally developed for
meeting the demands. We offer a broad range of ASTM A403 WP304 Stainless Steel Buttweld Pipe Fittings
through a worldwide network of stock-keeping branches. These ASTM A403 WP304 Buttweld Fittings is used in
various industries like :
Stainless Steel WP304 Buttweld Pipe Fitting uses in Oil and Gas Pipeline
ASTM A403 SS WP304 Buttweld Pipe Fittings uses in Chemical Industry
Grade 304 Stainless Steel Pipe Fittings uses in Plumbing
Stainless Steel ASTM A403 WP304 Buttweld Pipe Fittings uses in Heating
ASTM A403 WP304 Pipe Fittings uses in Water Supply Systems
ASTM A403 WP304 Stainless Steel Buttweld Fittings uses in Power Plant
SS 304 Buttweld Pipe Fittings uses in Paper & Pulp Industry
304 SS Buttweld Pipe Fittings uses in General Purpose Applications
ASME SA403 Stainless Steel WP304 Pipe Fittings uses in Fabrication Industry
Stainless Steel 304 Buttweld Fittings uses in Food Processing Industry
SS WP304 Buttweld Pipe Fittings uses in Structural Pipe
| Stainless Steel Seamless Pipe Fittings | Stainless Steel Welded Pipe Fittings |
| Stainless Steel Pipe Fittings | Stainless Steel Buttweld Pipe Fittings |
| ASTM A403 SS Welded Pipe Fittings | ASME SA403 SS Pipe Fittings |
| Stainless Steel Buttweld Pipe Elbow | Stainless Steel Buttweld Tee |
| SS Buttweld Reducer Suppliers | ANSI Stainless Steel Pipe Fittings |
| SS Buttweld Stubends | SS Pipe Fittings |
| SS Butt weld Fittings Stockholder | Steel Pipe End Cap |
| Stainless Steel 45deg. Elbow | SS 90deg. LR Elbow |
| Stainless Steel 180° LR Return Bends | Stainless Steel 180° SR Return Bends |
| Stainless Steel Buttweld Equal Tee | Stainless Steel Buttweld Cross |
| Stainless Steel Buttweld Reducing Nipple | Stainless Steel Short Radius Elbow |
| ANSI B16.9 SS Buttweld Fitting | SS End Pipe Cap |
| Stainless Steel Concentric Reducers | Stainless Steel Eccentric Reducers |
| Stainless Steel 3D Elbow | Stainless Steel 5D Elbow |
| Stainless Steel Elbows – Long Radius | Stainless Steel Stub Ends |
| Stainless Steel Elbows – Short Radius | Stainless Steel End Caps |
| Stainless Steel Reducing Elbows | Stainless Steel Reducing Crosses |
|
|
