45D Elbow
HOME ProductButted Weld Fittings
45D Elbow

45D Elbow

【Technology brief】

HGFF 45D Elbow .

【Material & Grades 】

Carbon Steel: ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.

Stainless Steel:ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN
1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

【Standard】

ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706



Description

HGFF GROUP. offers you an exquisite customer experience through our considerable product portfolio and a conscious and active customer-friendly team.

We engineer products that are feasible and advantageous in the long run. We are manufacturers and suppliers of Buttweld 45° Pipe Elbows, that is popularly called as ’45 Bends’. Joined to a pipe at a 45° angle, these pipes have a curve that produces a new 45° directional ow of the inner lid. Our Stainless Steel 45° Elbows are convenient to convey, are easy to handle, viable, reliable and come with a good surface finish.

They are customizable as well with a long life span. We are exporters of ANSI B16.9 Buttweld 45° Elbows that are supplied in various sizes and threads to the paper, breweries, agricultural, electronics, and food processing industry.

Product Structure

Standard Specication For Buttweld 45 Deg. Pipe Elbow
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Elbow ( 1/2″~24″), ERW / Welded / Fabricated Elbow (1/2″~48″)
Type : Seamless / ERW / Welded / Fabricated
Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and
etc.
Form : Elbow, 45 Deg Elbow, Long Radius Elbow, Short Radius Elbow, LR Elbow, SR Elbow.
Material & Grades of Buttweld 45 Deg. Pipe Elbow :
Stainless Steel Buttweld 45° Pipe Elbow :
ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN
1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Duplex & Super Duplex Steel Buttweld 45° Pipe Elbow :
ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werksto No. 1.4462
Carbon Steel Buttweld 45° Pipe Elbow :
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel 45° Pipe Elbow : ASTM A420 WPL3, A420 WPL6
Alloy Steel Buttweld 45° Pipe Elbow :
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Nickel Alloy Buttweld 45° Pipe Elbow :
ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No.
N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel
600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No.
N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.

Technical Parameters



Nominal External Center to end Thickness Kg
1/2″ 21 16 2.77 0.04
3/4″ 27 19 2.87 0.04
1″ 33 22 3.38 0.08
1 1/4″ 42 25 3.56 0.12
1 1/2″ 48 29 3.68 0.18
2″ 60 35 3.91 0.32
2 1/2″ 73 44 5.16 0.64
3″ 89 51 5.49 1.02
3 1/2″ 102 57 5.74 1.43
4″ 114 64 6.02 1.95
5″ 141 79 6.55 3.25
6″ 168 95 7.11 5.1
8″ 219 127 8.18 11.15
10″ 273 159 9.27 20.5
12″ 324 190 9.52 27
14″ 356 222 9.52 34
16″ 406 254 9.52 48
18″ 457 286 9.52 60
20″ 508 318 9.52 71.2
22″ 559 343 9.52 89
24″ 610 381 9.52 102.95
26″ 660 406 9.52 124.9
28″ 711 438 9.52 150
30″ 762 470 9.52 167
32″ 813 502 9.52 191
34″ 864 533 9.53 215
36″ 914 565 9.52 241
38″ 965 600 9.52 272
40″ 1016 632 9.52 290
42″ 1067 660 9.52 327
44″ 1118 695 9.52 363
46″ 1168 727 9.52 408
48″ 1219 759 9.52 443
